B406-S20C25D25 BMX CARBON RIMS AND CUSTOM WHEELS

20er-I25-D25 BSD406 bmx racing rims 32mm wide 25mm deep and customizable wheelss tubeless compatible

  • SPECS
  • FEATURES
  • WARRANTY
  • Product
    Item No.: B406-S20C25D25 Warranty: 2 Years (From purchase date)
    Basic
    Size: 20er Material: Toray Carbon Fiber (T700,T800) Rim Type: Clincher W/Hooks Tubeless: Compatible ERD: 373mm(Not including nipple head dimension) BSD: 406mm Outer Width: 32mm Inner Width: 25mm Rim Depth: 32mm Offset: 0 mm(Symmetric) Spoke Hole Angle: ±12° Spoke Hole Dia: 4.5mm Valve Hole Dia: 6.5mm(Presta Valve) Rim Bead Hole : 8.5mm
    Customization
    Brake System: Disc Disc | Non Disc/C-grooved Brake | Non Disc/AC3 grooved brake Version: SD:270±10g | SL:240±10g Hole Count: 24H | 28H | 32H | 16H | 18H | 20H | 21H | 36H | Custom | 0H Drilling Pattern: 1:1 Drilling | 2:1-T Drilling | 2:1-F Drilling | G3 Drilling | Custom Drilling Hole Type: Standard Holes | Staggered Drilling | Without Rim Bead Holes(Tubeless Ready) | Centered Line Drilling | Offset Drilling | Dual Drilling | Internal Nipple Holes | 2:1-F UST Drilling | 2:1-F Hidden Nipples Drilling | 2:1-F Standard Holes Drilling | 2:1-T US Drain Hole: No Drain Holes | Drain Holes | Weave: UD | 3K | 12K | Butterfly | Marble | 3K Twill Vertical | 3K Twill Horizontal | 12K Twill Vertical | 12K Twill Horizontal | 6-UD Braided | 8-UD Braied | 4-UD Braided | Custom Finish: Matte | Satin | Glossy | Paintless | Black Crystal | Silver Crystal | Purple Crystal | Blue Crystal | Colored | Matte Gold | Custom Decal: None/Black/White/Oil Slick/Red/Blue/Green/Orange/All Pantone Color/Lasered /
    Recommendation
    Weight Limit: ≤100kg Tire Size: 28~50C Spoke Tension: 120~130kgf for drive side Max Tire Pressure: Max 120psi recommended
    Explanation
    Standard Version: SD version is constructed by fully carbon fiber T700 Superlight Version: SL version is constructed by blend of carbon fiber T700 and T800
    Application
    SD Version: BMX SL Version: BMX
    Hubs
    Models: Custom Front Axle Size: Custom Rear Axle Size: Custom Driver Body: Custom
    Spokes
    Sapim: Custom Pillar: Custom Carbon Spoke: Custom Alpina: Custom
    Nipples
    Sapim: Custom Pillar: Custom
    Note
    Valve Kits: Provided if ordered Additional Request: Leave a note at checkout or contact us if you have special request ,such as spare spoke and nipples ,or mix nipple color for wheels build.
