ARG35TC30H 700C gravel rims 30mm wide 35mm deep tubeless for cyclocross and gravel bikes

ARG35TC30H ROAD CARBON RIMS AND WHEELS

700C gravel rims 30mm wide 35mm deep tubeless for cyclocross and gravel bikes

BUY NOW

Road Rims

Road Wheels

Brake System
Non disc version comes with a rim brake track,the disc version does not have a rim brake track.
Brake Surface
1.High TG Resin Brake Surface

2.Basalt Brake Surface

3.Grooved Graphene Brake Surface
Version
Our standard version (SD) are constructed by fully Toray T700 carbon fiber.The standard version is more suitable for heavier rider.It is recommended to choose heavy version if you are heavy user.

Our super light version (SL) are constructed by blend of Toray T800+T700 carbon fiber.The ultralight version is design for light rider who is keen on the lightest wheelsets.

If your cycling condition is special, such as extreme heavy rider, e-bike, tandems or wheelchair, please inform us of the specific requirements and USES, we will give you professional advice
Hole Count
If the number of holes you want is not listed,please contact us for assistance.All the spoke holes can be customized according to your requirements.
Please note that our valves are drilled for Presta and spoke holes are made for external nipples by default.If you have a custom drilling requirements,please reach out to us at sales@eiecarbon.comfor assistance.
Hole Type
1.Standard External Hole(Default Options)

2.Without Rim Bead Hole

3.Internal Nipple Hole

Our default/standard hole type is external hole.

If you need hidden hole or no rim bead holes options ,please select the options you needed.

All spoke type can be customized .Please contact us if you need any special orders.
Weave
Finish
Decal
1.Our current EIE graphic

2.Regular colors

In general ,black color is with black glossy by default if you select matte or satin finish.If your rim finish is glossy ,the black color is common water-slided decal which is under clear coating.
Valve Kits
1.One rim requests one valve stem.We will put correct length according to the rim depth you ordered.

2.One 10 meter roll of tape will be put into boxes if you ordered.It is typically covers 2pcs rim 2 laps each.We will give the correct wide according to the rim you ordered.

Brake System

Non disc version comes with a rim brake track,the disc version does not have a rim brake track.
Brake Surface
1.High TG Resin Brake Surface

2.Basalt Brake Surface

3.Grooved Graphene Brake Surface
Version

Our standard version (XC/AM/DH) are constructed by fully Toray T700 carbon fiber.The standard version is more suitable for heavier rider.It is recommended to choose heavy version if you are heavy user.

Our super light version (SL) are constructed by blend of Toray T800+T700 carbon fiber.The ultralight version is design for light rider who is keen on the lightest wheelsets

If your cycling condition is special, such as extreme heavy rider, e-bike, tandems or wheelchair, please inform us of the specific requirements and USES, we will give you professional advice
Hole Type
1.Standard External Hole(Default Options)

2.Without Rim Bead Hole

3.Internal Nipple Hole

Our default/standard hole type is external hole.

If you need hidden hole or no rim bead holes options ,please select the options you needed.

All spoke type can be customized .Please contact us if you need any special orders.
Weave
Finish
Decal
1.Our current EIE graphic

2.Regular colors

In general ,black color is with black glossy by default if you select matte or satin finish.If your rim finish is glossy ,the black color is common water-slided decal which is under clear coating.
Valve Kits
1.One rim requests one valve stem.We will put correct length according to the rim depth you ordered.

2.One 10 meter roll of tape will be put into boxes if you ordered.It is typically covers 2pcs rim 2 laps each.We will give the correct wide according to the rim you ordered.

Hub Brand
We keep in stock the popular axle sizes and colors of some well-liked hub models.If you want a special order which is not listed in the configurator,feel free to contact us (sales@eiecarbon.com).We will help you to check availabilty and pricing for your reference.

Available hubs brand for reference:

DT Swiss 240 EXP,DT SWISS 350,Bitex,Novatec,Extralite,Carbon Ti X-Hub,Chris King,White Industry,ARC,Choosen,Powerway,Fast Ace etc.

Front Axle Size:12/100mm,15*100mm,QR/100mm

Rear Axle Size: 12 / 142mm, QR/135mm

Driver Body: Shimano Road 11S,Shimano Road 11S Alloy,Sram XDR Alloy,Sram XDRM,Campy 11S Alloy

Hole Count: 24H ,28H
Front Axle

If the size you need is not listed, please contact us and we'll reach out to you to confirm your order.
By default, skewers are only offered with QR hubs
Rear Axle

If the size you need is not listed, please contact us and we'll reach out to you to confirm your order.
By default, skewers are only offered with QR hubs
Freehub Body

1. Shimano Road 11S works with 8/9/10-speed mountain cassette with a spacer(s).
2. Shimano MTB 10/11S works with 8/9-speed directly or 10-speed with a spacer or 11-speed road cassette if one of the inner cogs removed.

3. Campagnolo (Campy) 11S works with 9/10/11/12-speed Campy cassette with no spacers required.

4. Sram XDR could run XDR (road) cassette inherently and is compatible to run mountain bike XD cassette with a 1.85mm spacer.

5. Shimano Micro Spline (MS) works with 12-speed MS cassette only.
Disc Brake System

6-Bolt is the more common traditional option.Centerlock uses a unique interface and it is also convertable to 6-bolt. If you need the conversion kit, please contact us.
Our hubs are provided without rotor lock rings by default.
Holes Count F/R
If the number of holes you want is not listed,please contact us for assistance.All the spoke holes can be customized according to your requirements.
Please note that our valves are drilled for Presta and spoke holes are made for external nipples by default.If you have a custom drilling requirements,please reach out to us at sales@eiecarbon.comfor assistance.
Ratchet
NEW DT SWISS EXP RATCHET COMES WITH BELOW BENEFITS:

1.SIMPLE MAINTENANCE: No tool technology,make maintenance even simpler

2.FREEHUB BODY CONVERSION: Simplified due to easier disassembly.

3.LESS WEIGHT: Not only the reliability improved. The fusion of ratchet and threaded ring reduces the number of single parts of the system, which offers an important advantage.

4.LESS WEAR: A single cylindrical spring ensures faster full engagement and thus increases reliability.

5.SUPERIOR RELIABILITY: The full engagement of the ratchets creates a large contact surface and therefore low surface pressure that leads to superior reliability.

6.INCREASED BEARING LIFETIME: The integration of the bearing into the threaded ring allows the bearing distance to be maximized. The increased distance further supports the axis, which results in less deflection of the axle and thus protects the bearings and increases their lifetime.

EXP 36- With only a singlel spring, making the hubs faster and lighter, more complete engagement of the 36 ratchet teeth for more precise contact, and therefore a longer lifespan.

EXP 54 - Upgraded from EXP 36 to gain incredibly faster engagement.
Hub Color
Spoke
Nipple
We will randomly use one type of the nipples listed below to build wheels according to our inventory.If you have specific requirement,please leave a message when you make an order.

Sapim Polyax Secure Lock Black Brass Nipples

Sapim Polyax Secure Lock Black Aluminum Nipples

Sapim Aluminum Double Square Nipples

Sapim Polyax Secure Lock Green Nipples

Sapim Polyax Secure Lock Gold Nipples

Sapim Polyax Secure Lock Pink Nipples

Sapim Polyax Secure Lock Purple Nipples

Sapim Polyax Secure Lock Red Nipples

Sapim Polyax Secure Lock Silver Nipples

Sapim Polyax Secure Lock Blue Nipples

Pillar Black Aluminum MV Nipples

Pillar Gold Aluminum MV Nipples

Pillar Green Aluminum MV Nipples

Pillar Purple Aluminum MV Nipples

Pillar Red Aluminum MV Nipples

Pillar Silver Aluminum MV Nipples

USD:0 | Approx Weight: 0g

SPECS
TECH
WARRANTY

Product

Item: ARG35TC30H Warranty: 2 Years

Basic

Size: 700C Material: Toray (SD:T700 | SL:T700+T800 | UL:T800) Rim Type: Clincher W/Hookless Tubeless: Compatible ERD: 35mm Outer Width: 30mm Inner Width: 24mm Depth: 35mm Offset: 2.6mm Spoke Hole Angle: ±6° Spoke Hole Dia: 4.5mm Valve Hole Dia: 6.5mm Assembly Hole Dia: 7.5mm Weight: SD:410±15G | SL:370±15G | UL:340±15G

Customization

Weave: UD/3K/3K Twill/12K/12K Twill/others Finih: Matte/Glossy/Satin/Colored/Others Hole Count: 12H~36H

Recommendation

Weight Limit: ≤130kg Tire Size: 28C-50C Spoke Tension: 120~130kgf front disc side and rear drive side Tyre Pressure: ≤75psi/ 5.17bar

Application

SD: CX | Gravel SL: CX | Gravel

Note

1: SD(Standard/Common) version is constructed by fully carbon fiber T700 . 2: SL(Superlight) version is cnstructed by blend of carbon fiber T700+T800. 3: UL(Ultra-Lightweight) version is constructed by fully carbon fiber T800 .

HUBS

Model: DT SWISS 180, DT SWISS 240 EXP, DT SWISS 350, Chris King R45D, Novatec D411SB / D412SB, Carbon-Ti X-Hub, ARC MT-032, Bitex BX312F / BX312R Front Axle Size: 12*100mm,15*100mm,QR*100mm Rear Axle Size: 12 / 142mm, QR / 135mm,QR*130mm Driver Body: Shimano Road 11S,Sram XDR, Campy 11S Hole: 20H,24H,28H

OTHER PARTS

Spokes: Sapim CX-Ray,Sapim Race,Sapim D-Ligh,sapim CX Sprint,Pillar Aero X-TRA 1420,EIE Carbon Spoke ECS,Pillar 1423,Sapim Leader Nipples: Aluminium Black, Aluminium Red, Brass Black, Aluminium Blue, Aluminium Gold, Aluminium Green, Aluminium Orange, Aluminium Purple
All of our EIE road rims share with the following manufacturing technologies:

1.Super light WeightT700

The SD version were fully constructed Premium Toray T700 Carbon fiber.

T700+T800 component:The SL series EIE carbon rim were constructed with properly component of Toray T700+T800.

We cut the material size of the nipple bead area and strengthen the key parts of spokes to maintain the strength of the overall carbon rims.

2.Layer-up

The layer-up of each carbon rim is carefully designed, repeated tests and then determine final standards document.

After that,we’ll send it to our layer up workers, who operate according to the operating standards.They cut the size of the material according to the layer- up instructions to produce materials for any part that can be used to increase the strength of the side part of the wheel set, to fit the grooves of the rims, to enhance the impact resistance of the wheels.

All EIE's carbon rims were manufactured by a one-piece continuous layer.This uninterrupted layer not only produces a stronger rim, but a lighter one!

3.Angled Hole Drilled By CNC Machine

The spoke hole angle design of the rim is very important , but its design angle range is limited .If the design does not match the design of the spoke hole angle of the hub , the bending phenomenon of the spoke can be generated .

When our EIE carbon rims drill angled holes, the spacing and angle of each hole are calculated accurately to ensure that when the rim is connected to the drum through the stripes, no additional pressure is generated around the rim hole.

We use a high speed CNC machine to drill all the holes to avoid spoke holes area carbon fiber strength reduction ,thus making the wheels build stronger.

4.Smooth Rim Inside Surface

The air bladders are made from a special material which has ability to produce very smoother walls, result in a lighter rim, and are completely removed without harsh chemicals.They are removed through the valve hole with a unique process by a skillful workers .So you would not see any patched hole on rim bed,that produces a stronger rim.

5.High TG Rim Brake Track

All of EIE non disc brake surface were used for high TG resin system that to prevent the overheating while biking at high speed.It is combined with the grid 3K brake track ,that allows to withstand temperatures in excess of 280 degrees Celsius ,then dissipates heat ,and cooler rim temperatures quickly.

6.Grooved Graphene Brake Track

Our graphene version of the high TG brake track has better overheat resistance, improved heat dissipation, and reduced temperature accumulation during severe braking.The grooved brake tracks help to disperse the moisture between the pad and the brakes in wet conditions and bring more better braking resistance in dry conditions

7.Tubeless Compatible Technology(Tubular Except)

All of EIE tubess compatible rims are designed with bead seat on rim bed and a tire pump is needed to seal our rims while assembly .We from the actual use to consider the bead shape, bead seat and outer diameter to make sure the best fit with each rim.Even though tubeless (no tube is required) systems are required at lower pressures than tube systems,but without any negative effects.It improves better on lower rolling resistance, decreased rotational weight and flat resistance .
EIE Carbon offer this warranty is aimed to ensure that all products we sell are free from defects and all passed the QC test before shipment.
EIE Carbon carries 2-year warranty (from the date of purchasing) for all carbon bike rim we sell including the existing MTB rims ,road rims,fat bike rims,BMX rims and upcoming new models.

EIE Carbon Offer Warranty For Rims

1.Within 6 months from date of purchase:

If the rim quality issue is caused by manufacturing defects. EIE Carbon will send you the free replacement rim and bear the re-sending freight,but other expenses shall be adsorbed by the buyer.

2.After 6 months from date of purchase:

Free replace the damaged rims. EIE Carbon and customers shall bear 50% of the freight cost respectively.

EIE Carbon Offer Warranty For Wheels

1.Within 6 months from the date of purchase

1)Used

If the wheels quality is caused by rim manufacturing defects.EIE Carbon will send you the free replacement rim,bear the reshipment’s freight and compensate $30 for customers to rebuild wheels in local bike shop,but other expenses shall be adsorbed by the buyer.

2)Unused

If the wheels quality is caused by rim manufacturing defects.Customer is not allowed to use the wheels and EIE has right to ask buyer to send the whole wheels back to us.We will rearrange to send new wheels to customer after receiving the returned package within 2 weeks .In this case ,EIE will bear the shipping cost for returned package $50 at best as well as the shipping cost for resent package.The shipping cost of returned package will be refunded to customer by PayPal.The other expenses shall be adsorbed by the buyer.

If the wheels quality is caused by rim manufacturing defects and EIE does not need customer to send it back to us.EIE will send new free replacement rim to customer,bear the reshipment's freight and compensate $30 for customers to rebuild wheels at local bike shop,but other expenses shall be adsorbed by the buyer.

Extra problems like accessories please contact customer service for assistance

2.After 6 months after the date of purchase:

If the wheels quality is caused by rim manufacturing defects.EIE Carbon will send you the free replacement rim as well as bear the reshipment's freight .But other expenses shall be adsorbed by the buyer.

More at WARRANTY page.

PHOTOS

GUESTBOOK

visitor Daniel Blyth 2021-08-30

Hi There, I'm looking to upgrade my wheels on my gravel bike. I have a Cervelo Aspero which currently has heavy aluminum wheels and I wanted to get a wheel set that could handle up 700x 40mm tyres. I would prefer something that can handle clincher wheels but also ok if they they are only tubeless. When I look at your wheels I get confused at all the different profiles available. And the components for the hubs. What can you recommend as a middle of the road option ? I'm also not sure what the benefits are in the height of the dish as some seem very shallow and others deep. Obviously I want fast disc wheels but does have to be too expensive or fancy as it is for gravel. Thanks in advance.

EIE EIE Carbon:

@Daniel Blyth We will recommend our ARG35TC30H this model for 700X40mm tyres.As a middle of road options ,you can take a look wheels build with DT Swiss 350 or bitex hubs,spoke can select Pillar 1420 which is alternative of Sapim CX-Ray . What about your bike frame specs?We can have a look and give you some suitable suggestion. Thanks EIECarbon

2021-09-06

Reply

Name:

Email:
visitor Bruce Schwab 2022-06-19

Looking for 30mm wide 700c rims....one x 24H, and one x 28H Shipping to Maine, USA. Where do you ship from?

EIE EIE Carbon:

@Bruce Schwab Thank you for your inquiry. According to your requirement ,we suggest our SR30TC26 this model which can be met your demand.We are no problem to drill one 24H and one 28H .Our facility is located in China ,so the items will be shipped from China.Shipping to USA by EMS will take around 2 weeks now . If any question ,please feel free to contact us . Thanks EIECarbon

2022-08-26

Reply
